On Sale Products
-
MIL DTL 5015 Circular Connector, MS3108A Type Right Angle Plug, Socket Contacts, Solder Pin, Threaded
₹10.00 – ₹799.00
-
MIL-C-5015 Circular Connector, MS3102A Type Box Mounting Receptacle, Pin Contacts, Solder Pin, Threaded
$ 0.90 –
-
MIL-DTL-5015 VG95234 Series Circular Connector, CA3108A Type Right Angle Plug, Socket Contacts, Solder Pin, Reverse Bayonet
$ 0.90 –
Sale!
MIL DTL 5015 Circular Connector, MS3108A Type Right Angle Plug, Socket Contacts, Solder Pin, Threaded
$ 0.90
MIL DTL 5015 Circular Connector, MS3108A Type Right Angle Plug, Socket Contacts, Solder Pin, Threaded Introduction: Metabee’s MIL-DTL-5015 (formerly MIL-C-5015) series mil-spec circular connectors meet the performance requirements of the MIL-DTL-5015 (now SAE-SA50151). To ensure that our customers receive high-quality connectors, we use only the best materials, precision production, and strict quality control procedures. Features of this MIL DTL 5015 Circular Connector: Threaded coupling High-strength aluminum alloy connector; High-strength plastic insulators; Environmentally safe shell finishes; Protected against corrosion; IP67 rating; High-quality plating finish; Machined contacts; Competitive prices. Main Specifications: General Information: Product Type: MIL-DTL-5015 series Mil Spec Circular Connector Series: MS3108A Number of Positions: 1-37Pin Shell Sizes: 10SL/12S/14S/16S/16/18/20/22/24/28/32/36 Contact Type: Socket Contacts Orientation: Right Angle Durability: 500 cycles Contact Sizes: 0AWG, 4AWG, 8AWG, 12AWG, 16AWG Coupling Method: Threaded Temperature Range: -55°C ~ 125°C Protection Degree: IP67 Materials and Plating: Shell Material: Aluminum alloy Shell Plating: Green and black zinc alloy plating Contact Material: Copper Alloy Contact Plating: Silver Insulator Material: PPS Plastic / Silicone Rubber Electrical Performance: Rated voltage: 500V (Normal temperature), 250V (High temperature) Rated current: 13A for 16AWG/23A for 12AWG/46A for 8AWG/80A for 4AWG/150A for 0AWG Insulation Resistance: 5,000 Mega ohms minimum (at 25°C) Contact Resistance: ≤10 mΩ How to Order: Connector Size: MS3108A Right Angle plugs have a solid endbell and are used when wire needs to be brought at an acute angle. Either the split or solid endbells can be rotated and locked. Applications of this MIL DTL 5015 Circular Connector: Military & Defense Aerospace & Space Railway & Mass Transit Industrial & Heavy Equipment Alternative Energy, Nuclear, Oil & Gas Download the MIL-DTL-5015 (formally MIL-C-5015) Circular Connectors PDF Catalog: MIL-DTL-5015 Series Mil Spec Circular Connectors Catalog (PDF, 2.2 MB) Learn more about our military connectors. Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now! Metabee is a professional connector manufacturer from China. We promise to provide you with high-quality products and excellent services.
