USDX 8-Band SDR QRP Transceiver 3-5W | All Mode HF Radio with DSP for 80m to 10m Bands Elevate your QRP adventures with the R1.02W 3-5W USDX SDR Transceiver, an advanced all-mode HF ham radio designed for portable and field operations. This upgraded USDX model expands to 8 bands (80m/3.5MHz, 60m/5.3MHz, 40m/7MHz, 30m/10.1MHz, 20m/14MHz, 17m/18.1MHz, 15m/21MHz, 10m/28MHz), supporting LSB, USB, CW, AM, FM, and digital modes like FT8. Delivering 3-5W output power with efficient Class-E amplification, it features embedded DSP (Digital Signal Processing) for noise reduction, AGC, and filtering, plus SDR architecture for software upgrades. Housed in a rugged aluminum case with a crisp 1602 LCD display and stable TCXO (0.5PPM), the R1.02W includes VOX, built-in keyer, and easy firmware flashing via USB. Ideal for SOTA (Summits on the Air), POTA, and DXing, this open-source-inspired transceiver offers exceptional value for ham radio enthusiasts seeking multi-band versatility in a compact 10cm x 7.5cm x 3cm form factor. 3W-5W USDX HF Transceiver Shortwave QRP SSB/CW Transceiver All Mode 8 Band Upgraded Version Of USDX Note: -Due to different production batches, the goods may have different appearance but with the same effect. The picture is for reference only, subject to the actual product delivered! -AM and FM are gifts, this function is not supported by the product, if you mind, please do not place an order! Description: This is a shortwave QRP SSB/CW transceiver. Ultra-small size makes it easy to carry for outdoor use. It boasts a 1602N LCD screen and a built-in speaker. It supports connection to a PC and uses FT8, JS8, FT4 and other digital mode software control, and supports CW automatic decoding. Features: – 8 bands: 3.5Mhz～3.9MHz, 5351.5-5366.5kHz, 7MHz～7.3MHz, 10.1MHz～10.150MHz, 14MHz～14.350MHz, 18.068 MHz～18.168MHz, 21MHz～21.450MHz and 28MHz～29.700MHz – Excellent PCB layout design in line with high-frequency circuit design principles to ensure excellent performance – Whether using an external 13.8v power supply, it can reach 3-5W power in 8 bands, and reserve the SOT-223 and TO-220 package pads required for upgrading – High emission efficiency, 80m/60m/40m/30m/20m efficiency is higher than 80%, 17m efficiency is higher than 70%, 15m/10m efficiency is higher than 60% – High-precision TCXO for KDS, frequency accuracy is better than 1PPM, frequency stability is better than 0.5PPM – Ultra-small size: 83 x 38 x 124mm/3.3 x 1.5 x 4.9″ (excluding protruding parts) – Abundant interfaces (CAT, PTT OUT, MIC/KEY, K-head microphone) – All LPF parts use 100V C0G/NP0 capacitors – Use original magnetic latching relays for Omron – Use op amp chip with lower noise than LM4562 – Built-in speaker with cavity – BNC antenna interface List of Functions: – Simple, fun and versatile QRP SSB HF transceiver with embedded DSP and SDR functions; – EER Class-E driven SSB transmit-stage – Approximately 5W PEP SSB output from 13.8V supply – All-Mode support: USB, LSB, CW, AM, FM – DSP filters: 4000, 2500, 1700, 500, 200, 100, 50 Hz pass-band – DSP features: Automatic Gain Control (AGC), Noise-reduction (NR), Voice-triggered Xmit (VOX), RX Attenuators (ATT), TX noise gate, TX drive control, Volume control, dBm/S-meter – SSB opposite side-band/carrier suppression Transmit: better than -45dBc, IMD3 (two-tone) -33dBc, Receive: better than -50dBc – Multi-band support, continuously tunable through bands 160m-10m (and from 20kHz to 99MHz with loss in performance) – Open source firmware, built with Arduino IDE; allows experimentation, new features can be added, contributions can be shared via Github, software-complexity: 2000 lines of code – Software-based VOX that can be used as fast Full Break-In (QSK and semi-QSK operation) or assist in RX/TX switching for operating digital modes (no CAT or PTT interface required), external PTT output/PA control with TX-delay – Simple to install modification with 8 component changes and 8 wires – Lightweight and low-cost transceiver design: because of the EER-transmitter class-E stage it is highly power-efficient (no bulky heatsinks required), and has a simple design (no complex balanced linear power amplifier required) – Fully digital and software-based SSB transmit-stage: samples microphone-input and reconstruct a SSB-signal by controlling the phase of the SI5351 PLL (through tiny frequency changes over 800kbits/s I2C) and the amplitude of the PA (through PWM of the PA key-shaping circuit) – Fully digital and software-based SDR receiver-stages (optionally): samples I/Q (complex) signal from Quadrature – Sampling Detector digital mixer, and performs a 90-degree phase-shift mathematically in software (Hilbert-transform) and cancels out one side-band by adding them – Three independent switchable analog front-end receiver attenuators (0dB, -13dB, -20dB, -33dB, -53dB, -60dB, -73dB) – Receiver Noise floor MDS: -135 dBm at 28MHz (in 200Hz BW) – Receiver Front-end selectivity: steep -45dB/decade roll-off /-2kHz from tuned-frequency – Blocking dynamic range: 20kHz offset 123dB, 2kHz offset 78dB – CW decoder, Straight/Iambic-A/B keyer – VFO A/B RIT and Split, and corresponding relay band-filter switching via I2C – CAT support (TS480 subset) Specifications: – Type: HF QRP SDR Transceiver – Mode: SSB/CW – Rf output: 10W max at 13.8V exit DC in – Frequency range: 3.5-30MHz – Built-in MIC – Antenna/connector: 50Ω/SO-239 With battery Package Included: – 1 x Transceiver – 1 x Handheld Mic – 1 x power supply – With built-in 4000mah lithium battery
